Industrial Sockets

POWER DRIVES impact sockets are designed for professional tool users. They are engineered specifically for use with impact tools using the most up to date industrial specifications. Impact sockets are made with thicker walls and tempered to a lower hardness so as not to shatter under the impacts. They are typically finished in black oxide rather than the chrome plating typical of the hand-tool variety.  Since impact sockets are used in demanding applications, impact sockets are designed to sustain the impacts. Look inside the square drive hole for a mark in the metal that looks like it’s been gouged with a fingernail. This indicates that the drive has been formed by pushing a rod through the metal during the forging process, Impact sockets are available in different sizes and types. A few common types that are used are as under:

·        6 Point Standard Impact Sockets

·        6 Point Deep Impact Sockets

·        12 Point Standard Impact Sockets

·        12 Point Deep Impact Sockets

·        4 Point Standard

·        8 Point Standard

·        Thin Wall Impact Sockets -Standard

POWER DRIVES' IMPACT SOCKETS ‘POWER DRIVES' freecorner Standard, Deep and Thinwall Sockets Up to 3.1/2" square drive Impact Sockets through to 235MM (9.1/8") across the flats # 5 spline drive to across the flats Wide variety of Accessories PROFILE The profile is provided on the square drives as well as on the hexagon end of Impact Sockets 1/2" square drive and above. The benefits of the profile include are Reduced risk of fastener rounding. Increased chances of turning worn fasteners. Impact Sockets of 1/2" square drive and above feature for flats above 17 mm (5/8"). All Impact Sockets are made from high strength alloy steel. All Impact Sockets are heat treated for the best combination of strength and impact resistance. All Impact Sockets have an optimum wall thickness for strength and access on fasteners having restrictions. The depth of the Hex openings is designed to accomodate the full standard fastener head. All Impact Sockets have chamfered openings for ease in engagement with the drive tool and the fastener. Concentric openings and large clearance holes to meet industrial specifications. All Impact Sockets have a Ring-N-Pin arrangement for securing them to the drive. Sockets are plated and black oxidized coated for increased protection from rusting. CONVENTIONAL PROFILE Corner point contact high stress areas FREECORNER PROFILE Distributed surface loads relieves possible stress area Highlights show contact points on the corner of the fastener Highlights show contact points away from the corner of the fastener 2POWER DRIVES IMPACT SOCKETS, ACCESSORIES AND SOCKET SETS The POWER DRIVES warranty will replace free to the original purchaser any qualifying socket found to be defective in either material or workmanship, indicated by premature wear or breakage. Determination of free replacement will be done by your POWER DRIVES distributor. POWER DRIVES WARRANTY 3/8” SQUARE DRIVE IMPACT SOCKETS 1/2” SQUARE DRIVE IMPACT SOCKETS 3/4” SQUARE DRIVE IMPACT SOCKETS 1” SQUARE DRIVE IMPACT SOCKETS 1.1/2” SQUARE DRIVE IMPACT SOCKETS 2.1/2” SQUARE DRIVE IMPACT SOCKETS 3.1/2” SQUARE DRIVE IMPACT SOCKETS # 5 SPLINE DRIVE IMPACT SOCKETS

POWER DRIVES impact sockets are designed for professional tool users. They are engineered specifically for use with impact tools using the most up to date industrial specifications. Impact sockets are made with thicker walls and tempered to a lower hardness so as not to shatter under the impacts. They are typically finished in black oxide rather than the chrome plating typical of the hand-tool variety.  Since impact sockets are used in demanding applications, impact sockets are designed to sustain the impacts. Look inside the square drive hole for a mark in the metal that looks like it’s been gouged with a fingernail. This indicates that the drive has been formed by pushing a rod through the metal during the forging process, Impact sockets are available in different sizes and types. A few common types that are used are as under:

·        6 Point Standard Impact Sockets

·        6 Point Deep Impact Sockets

·        12 Point Standard Impact Sockets

·        12 Point Deep Impact Sockets

·        4 Point Standard

·        8 Point Standard

·        Thin Wall Impact Sockets -Standard

POWER DRIVES' IMPACT SOCKETS ‘POWER DRIVES' freecorner Standard, Deep and Thinwall Sockets Up to 3.1/2" square drive Impact Sockets through to 235MM (9.1/8") across the flats # 5 spline drive to across the flats Wide variety of Accessories PROFILE The profile is provided on the square drives as well as on the hexagon end of Impact Sockets 1/2" square drive and above. The benefits of the profile include are Reduced risk of fastener rounding. Increased chances of turning worn fasteners. Impact Sockets of 1/2" square drive and above feature for flats above 17 mm (5/8"). All Impact Sockets are made from high strength alloy steel. All Impact Sockets are heat treated for the best combination of strength and impact resistance. All Impact Sockets have an optimum wall thickness for strength and access on fasteners having restrictions. The depth of the Hex openings is designed to accomodate the full standard fastener head. All Impact Sockets have chamfered openings for ease in engagement with the drive tool and the fastener. Concentric openings and large clearance holes to meet industrial specifications. All Impact Sockets have a Ring-N-Pin arrangement for securing them to the drive. Sockets are plated and black oxidized coated for increased protection from rusting. CONVENTIONAL PROFILE Corner point contact high stress areas FREECORNER PROFILE Distributed surface loads relieves possible stress area Highlights show contact points on the corner of the fastener Highlights show contact points away from the corner of the fastener 2POWER DRIVES IMPACT SOCKETS, ACCESSORIES AND SOCKET SETS The POWER DRIVES warranty will replace free to the original purchaser any qualifying socket found to be defective in either material or workmanship, indicated by premature wear or breakage. Determination of free replacement will be done by your POWER DRIVES distributor. POWER DRIVES WARRANTY 3/8” SQUARE DRIVE IMPACT SOCKETS 1/2” SQUARE DRIVE IMPACT SOCKETS 3/4” SQUARE DRIVE IMPACT SOCKETS 1” SQUARE DRIVE IMPACT SOCKETS 1.1/2” SQUARE DRIVE IMPACT SOCKETS 2.1/2” SQUARE DRIVE IMPACT SOCKETS 3.1/2” SQUARE DRIVE IMPACT SOCKETS # 5 SPLINE DRIVE IMPACT SOCKETS

A Heavy-Duty Impact Socket with a 1-1/2" square drive, Byhex (or Bi-Hexagon), and 12-point

Socket Specifications:

1. 1-1/2" Square Drive:

   • Drive Size: The 1-1/2" square drive indicates a large drive size, suitable for heavy-duty impact wrenches or ratchets. This size is commonly used in industrial applications and for large fasteners.
   • Impact Tools Compatibility: Ensure that your impact wrench or ratchet has a 1-1/2" square drive to match the socket.

2. Byhex (Bi-Hexagon) Design:

   • Design Purpose: The Byhex (also known as Bi-Hex or 12-Point) design provides 12 contact points with the fastener, which helps in distributing the torque more evenly and reduces the risk of rounding off the fastener edges.
   • Improved Grip: This design often improves the grip on fasteners, making it easier to handle stubborn or heavily torqued fasteners.

3. Heavy-Duty Construction:

   • Material: Typically made from high-strength materials like chrome molybdenum or chrome vanadium steel. These materials are heat-treated to enhance toughness and resistance to impact forces.
   • Durability: Designed to withstand high-impact forces and repeated use without deformation or failure.

Applications:

1. Automotive:

   • Large Fasteners: Used in applications where large fasteners are common, such as in heavy-duty trucks, large machinery, or engine components.

2. Industrial:

   • Machinery Maintenance: Ideal for maintenance and assembly tasks involving large industrial machinery or equipment.

3. Construction:

   • Heavy Equipment: Useful for assembling or disassembling heavy construction equipment and other large components.

Benefits:

1. Enhanced Torque Transfer:

   • Torque Handling: Designed to handle high torque levels without slipping or damaging the fastener.

2. Reduced Fastener Damage:

   • Less Rounding: The 12-point design minimizes the risk of rounding off fastener corners compared to traditional 6-point sockets.

3. Versatility:

   • Wide Range of Use: Suitable for various heavy-duty applications and compatible with impact tools designed for large drive sizes.

Choosing the Right Socket:

1. Verify Compatibility:

   • Drive Size: Ensure that the 1-1/2" drive size matches your tool and is appropriate for your application.
   • Socket Size: Verify that the socket size is correct for the fasteners you're working with.

2. Material and Finish:

   • Quality Material: Choose a socket made from durable materials, such as chrome molybdenum or chrome vanadium, and check for any corrosion-resistant finishes.

3. Brand and Quality:

   • Reputable Brands: Look for well-regarded brands known for producing high-quality impact sockets, such as Snap-on, Matco Tools, or DeWalt.
   • Reviews: Check product reviews to ensure the socket meets your expectations for durability and performance.

4. Price and Value:

   • Cost vs. Longevity: Higher-quality sockets might cost more but often provide better performance and longevity. Consider the balance between cost and durability.

POWER DRIVES impact sockets are designed for professional tool users. They are engineered specifically for use with impact tools using the most up to date industrial specifications. Impact sockets are made with thicker walls and tempered to a lower hardness so as not to shatter under the impacts. They are typically finished in black oxide rather than the chrome plating typical of the hand-tool variety.  Since impact sockets are used in demanding applications, impact sockets are designed to sustain the impacts. Look inside the square drive hole for a mark in the metal that looks like it’s been gouged with a fingernail. This indicates that the drive has been formed by pushing a rod through the metal during the forging process, Impact sockets are available in different sizes and types. A few common types that are used are as under:

·        6 Point Standard Impact Sockets

·        6 Point Deep Impact Sockets

·        12 Point Standard Impact Sockets

·        12 Point Deep Impact Sockets

·        4 Point Standard

·        8 Point Standard

·        Thin Wall Impact Sockets -Standard

POWER DRIVES' IMPACT SOCKETS ‘POWER DRIVES' freecorner Standard, Deep and Thinwall Sockets Up to 3.1/2" square drive Impact Sockets through to 235MM (9.1/8") across the flats # 5 spline drive to across the flats Wide variety of Accessories PROFILE The profile is provided on the square drives as well as on the hexagon end of Impact Sockets 1/2" square drive and above. The benefits of the profile include are Reduced risk of fastener rounding. Increased chances of turning worn fasteners. Impact Sockets of 1/2" square drive and above feature for flats above 17 mm (5/8"). All Impact Sockets are made from high strength alloy steel. All Impact Sockets are heat treated for the best combination of strength and impact resistance. All Impact Sockets have an optimum wall thickness for strength and access on fasteners having restrictions. The depth of the Hex openings is designed to accomodate the full standard fastener head. All Impact Sockets have chamfered openings for ease in engagement with the drive tool and the fastener. Concentric openings and large clearance holes to meet industrial specifications. All Impact Sockets have a Ring-N-Pin arrangement for securing them to the drive. Sockets are plated and black oxidized coated for increased protection from rusting. CONVENTIONAL PROFILE Corner point contact high stress areas FREECORNER PROFILE Distributed surface loads relieves possible stress area Highlights show contact points on the corner of the fastener Highlights show contact points away from the corner of the fastener 2POWER DRIVES IMPACT SOCKETS, ACCESSORIES AND SOCKET SETS The POWER DRIVES warranty will replace free to the original purchaser any qualifying socket found to be defective in either material or workmanship, indicated by premature wear or breakage. Determination of free replacement will be done by your POWER DRIVES distributor. POWER DRIVES WARRANTY 3/8” SQUARE DRIVE IMPACT SOCKETS 1/2” SQUARE DRIVE IMPACT SOCKETS 3/4” SQUARE DRIVE IMPACT SOCKETS 1” SQUARE DRIVE IMPACT SOCKETS 1.1/2” SQUARE DRIVE IMPACT SOCKETS 2.1/2” SQUARE DRIVE IMPACT SOCKETS 3.1/2” SQUARE DRIVE IMPACT SOCKETS # 5 SPLINE DRIVE IMPACT SOCKETS

These 3/4" drive impact socket adapters have a three-quarter inch square drive that's compatible with drive tools of the same size.

POWER DRIVES impact sockets are designed for professional tool users. They are engineered specifically for use with impact tools using the most up to date industrial specifications. Impact sockets are made with thicker walls and tempered to a lower hardness so as not to shatter under the impacts. They are typically finished in black oxide rather than the chrome plating typical of the hand-tool variety.  Since impact sockets are used in demanding applications, impact sockets are designed to sustain the impacts. Look inside the square drive hole for a mark in the metal that looks like it’s been gouged with a fingernail. This indicates that the drive has been formed by pushing a rod through the metal during the forging process, Impact sockets are available in different sizes and types. A few common types that are used are as under:

·        6 Point Standard Impact Sockets

·        6 Point Deep Impact Sockets

·        12 Point Standard Impact Sockets

·        12 Point Deep Impact Sockets

·        4 Point Standard

·        8 Point Standard

·        Thin Wall Impact Sockets -Standard

POWER DRIVES' IMPACT SOCKETS ‘POWER DRIVES' freecorner Standard, Deep and Thinwall Sockets Up to 3.1/2" square drive Impact Sockets through to 235MM (9.1/8") across the flats # 5 spline drive to across the flats Wide variety of Accessories PROFILE The profile is provided on the square drives as well as on the hexagon end of Impact Sockets 1/2" square drive and above. The benefits of the profile include are Reduced risk of fastener rounding. Increased chances of turning worn fasteners. Impact Sockets of 1/2" square drive and above feature for flats above 17 mm (5/8"). All Impact Sockets are made from high strength alloy steel. All Impact Sockets are heat treated for the best combination of strength and impact resistance. All Impact Sockets have an optimum wall thickness for strength and access on fasteners having restrictions. The depth of the Hex openings is designed to accomodate the full standard fastener head. All Impact Sockets have chamfered openings for ease in engagement with the drive tool and the fastener. Concentric openings and large clearance holes to meet industrial specifications. All Impact Sockets have a Ring-N-Pin arrangement for securing them to the drive. Sockets are plated and black oxidized coated for increased protection from rusting. CONVENTIONAL PROFILE Corner point contact high stress areas FREECORNER PROFILE Distributed surface loads relieves possible stress area Highlights show contact points on the corner of the fastener Highlights show contact points away from the corner of the fastener 2POWER DRIVES IMPACT SOCKETS, ACCESSORIES AND SOCKET SETS The POWER DRIVES warranty will replace free to the original purchaser any qualifying socket found to be defective in either material or workmanship, indicated by premature wear or breakage. Determination of free replacement will be done by your POWER DRIVES distributor. POWER DRIVES WARRANTY 3/8” SQUARE DRIVE IMPACT SOCKETS 1/2” SQUARE DRIVE IMPACT SOCKETS 3/4” SQUARE DRIVE IMPACT SOCKETS 1” SQUARE DRIVE IMPACT SOCKETS 1.1/2” SQUARE DRIVE IMPACT SOCKETS 2.1/2” SQUARE DRIVE IMPACT SOCKETS 3.1/2” SQUARE DRIVE IMPACT SOCKETS # 5 SPLINE DRIVE IMPACT SOCKETS

Proto is a well-known brand that produces a wide range of hand tools and industrial equipment, including impact sockets. Proto impact sockets are designed to withstand high torque and heavy-duty applications, making them suitable for tasks where traditional sockets might not be able to handle the stress. Here are some key features and information about Proto impact sockets: Material: Proto impact sockets are typically made from high-quality materials such as chrome molybdenum steel or other high-strength alloys. This material provides durability and the ability to handle the force generated by impact tools, like pneumatic or electric impact wrenches. Impact-Ready: Proto impact sockets are specifically designed for use with impact wrenches, which deliver sudden, powerful bursts of force. These sockets are constructed to withstand the stress and vibration associated with impact tools. Sizing: Proto offers a wide range of socket sizes, including both metric and imperial measurements. They come in various drive sizes (e.g., 1/4-inch, 3/8-inch, 1/2-inch, 3/4-inch, 1-inch, etc.) to fit different tools and applications. Socket Types: Proto manufactures various types of impact sockets, including standard deep sockets, shallow sockets, universal sockets, and others. Universal sockets are designed to fit multiple fastener types (e.g., 6-point and 12-point), providing versatility.

Markings: Proto impact sockets often feature clear and permanent markings that indicate the socket size, making it easy to identify the right socket for the job.  Corrosion Resistance: Many Proto impact sockets are treated with a black oxide finish or other anti-corrosion coatings to protect them from rust and other environmental factors.

 Proto Brand: Proto is a subsidiary of Stanley Black & Decker, which is known for producing high-quality tools and equipment. Proto tools are respected in the industry for their durability and performance.

When working on heavy machinery or automotive applications that require high torque and force, it's important to use the right tools, including impact sockets. Proto is one of many reputable brands that produce impact sockets, so you can choose the specific sockets that meet your needs and are compatible with your impact tools. Be sure to select the correct size and type of socket for your specific task to ensure safety and efficiency.

Certainly, here are some additional details and considerations when it comes to Proto impact sockets:

Socket Design: Proto impact sockets typically have a thick and robust design to handle the intense forces generated by impact tools. They are less likely to crack or shatter compared to standard sockets when used with impact wrenches.

Hex Configuration: Most impact sockets have a 6-point (hex) configuration. This design provides better contact and grip on fasteners, reducing the likelihood of rounding off corners, which can occur with 12-point sockets.

Size Range: Proto offers a wide range of socket sizes to accommodate various applications. From small socket sizes for precision work to large sockets for heavy machinery and construction tasks, Proto has you covered. Drive Size Compatibility: Ensure that the impact sockets you choose match the drive size of your impact wrench. For example, if you have a 1/2-inch drive impact wrench, make sure you select 1/2-inch drive impact sockets. Socket Depth: Proto impact sockets come in different depths, including standard depth and deep sockets. Choose the appropriate depth based on the clearance and accessibility of the fasteners you need to work on. Impact Socket Sets: Proto often offers impact socket sets that include an assortment of socket sizes in a convenient carrying case. These sets can be a cost-effective way to acquire a range of socket sizes for your tool collection.

The term "VDE 1000V Insulated Socket Set" refers to a set of sockets that are designed and tested to meet the safety standards outlined by the Verband der Elektrotechnik (VDE), which is the Association for Electrical, Electronic, and Information Technologies in Germany. The "1000V" indicates that the tools in the set are insulated and rated for use in electrical systems with voltages up to 1000 volts.

Here are some key points about VDE 1000V insulated tools:

1. Insulation: The tools in the set, including sockets, are insulated to prevent electrical conductivity. This insulation is crucial when working with electrical systems to protect the user from electric shock.

2. Testing Standards: VDE is known for its stringent testing standards. Tools that meet VDE standards undergo rigorous testing to ensure their safety and effectiveness in electrical work.

3. Application: The VDE 1000V insulated socket set is specifically designed for use in electrical applications. Electricians and professionals working on or near live electrical components use these tools to reduce the risk of electrical accidents.

4. Material: The sockets in the set are typically made from high-quality materials that offer good mechanical strength and durability. The insulation is often made of materials that provide protection against electrical conductivity.

5. Color Coding: VDE tools often incorporate color-coding to help users quickly identify the insulation level. For example, yellow is a common color for 1000V insulation.

When working on electrical systems, it's crucial to use tools that meet safety standards to minimize the risk of injury or damage. Always check that your tools are properly insulated and rated for the voltage levels you are working with. Additionally, following safety guidelines and procedures is essential for anyone working with electricity. Certainly, let's delve a bit deeper into the components and features of a VDE 1000V insulated socket set:

1. Socket Types: The set may include a variety of socket types to accommodate different fasteners and applications. Common types include hex sockets, Torx sockets, and others. Having a diverse set ensures that the electrician or technician has the right tool for the job.

2. Ratchets and Extensions: In addition to sockets, the set may include insulated ratchets and extensions. Ratchets are used to apply torque to fasteners, and extensions provide reach in confined spaces. Both are crucial for versatility in electrical work.

3. Insulation Material: The insulation on VDE tools is often made from materials like high-quality polymers or rubber. These materials are not only good insulators but are also resistant to wear, tear, and common chemicals encountered in industrial environments.

4. Testing and Certification: VDE 1000V insulated tools are subjected to thorough testing to ensure their compliance with safety standards. The tools may bear a certification mark from VDE or other relevant authorities, indicating that they meet or exceed safety requirements.

5. Storage Case: Many sets come in a durable storage case to keep the tools organized and protected when not in use. This is especially important for maintaining the integrity of the insulation and ensuring that the tools are readily accessible.

6. User Guidelines: Manufacturers often provide guidelines for the proper use and maintenance of VDE tools. Users should follow these guidelines to ensure the longevity and safety of the tools.

7. Maintenance and Inspection: Regular inspection of the insulation is crucial. Any signs of wear, damage, or cracking should be addressed immediately, and the tool should be taken out of service if its insulation is compromised.
